What Is Inconel 601

2020-05-02

Description Of Inconel 601


Inconel 601 is a nickel-chromium alloy with excellent oxidation resistance at 1200 ° C. Alloy 601 can produce a dense oxide layer to prevent oxidation in harsh circulating thermal environments.


what is inconel 601-PTJ CNC MACHINING Shop
Description Of Inconel 601. -PTJ CNC MACHINING Shop

The Inconel 601 has excellent high-temperature strength, and can maintain its unique toughness even in a high-temperature environment for a long time. 601 inconel alloy also has good corrosion resistance under oxidizing conditions. However, it is not recommended to use 601 alloy in a strong reducing and vulcanizing environment.

Due to its huge oxidation resistance, 601 alloy should be welded with the corresponding 601GTAW welding wire. The welding material of RA602CA has stronger oxidation resistance than 601 base material, so the welding material of RA602CA can also be applied to the welding of 601 alloy. 601 alloy is more difficult to machine than 304 stainless steel. Its processing level is equivalent to 15-20% of AISI B 1112

Material standards

AMS 5715
ASME SB 168
ASTM B 168

Product form

601 rolls, 601 sheets, 601 tubes, 601 sheets

Common Trade Names
Alloy 601, Inconel601, Nickel 601

Material properties

Excellent oxidation resistance at 1100 degrees
Excellent carbonization resistance
Good creep rupture strength
Main applications of stable metallurgical performance

Main Application

Brazed zinc, annealed and sintered muffle furnace and Zhen furnace.
Radiant tube
Wire annealing tube
Steam high temperature heating tube assembly
Rotary kiln and sintering furnace
Thermal (electric) coupler protection tube

Physical Properties

Density: 0.85
Melting point range: 1375-1495 ° F
Temperature, ° F 70 1000 1200 1400 1600 1800 2000
Coefficient of thermal expansion, in / in ° F x 10-6-8.5 8.9 9.2 9.5 9.8 10.2
Thermal conductivity
Btu • ft / ft2 • hr • ° F 6.5 11.6 12.7 13.7 14.8 15.8 16.9
Modulus of Elasticity, Dynamic psi x 106 29.95 25.43 24.12 22.48 20.54 18.43 16.20
* 70 ° F to indicated temperature.

Material mechanical properties

Short-term high-temperature tensile properties

Temperature, ° F 70 1000 1200 1400 1600
Tensile strength, ksi 100 90 60 34 18
0.2% yield strength, ksi 54 48 41 26 15
Elongation,% 45 44 45 70 120
Typical creep fracture performance
Temperature, ° F 1400 1600 1800 2000
Minimum creep 0.0001% / Hour, ksi 4.1 2.0 0.76 0.43
Break at 10,000 hours, ksi 6.2 2.6 1.2 0.62 *
